| Machine type | Pipe Bending Machine |
| Material / Metal Processed | Alloy, Brass / Copper, Carbon steel, stainless steel, Aluminum |
| Max. bending angle (deg) | 190 |
| Bending precision (deg) | +/-0.1 |
| Automation | Semi-automatic |
| Power (kw) | 15 |
| Weight (kg) | 3800 |
| Warranty | 1 Year |
| Video Outgoing-Inspection | Provided |
| Machinery Test Report | Provided |
| Place of Origin | Jiangsu, China |
| Brand Name | JBORU |
| Core components | Bearing, motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox |
| Bending radius (mm) | 20 – 450 |
| Key selling points | Multifunctional |
| Name | Full-auto Tube Bender |
| Application | Pipes Processing |
| Product name | Pipe Profile Bending Machine |
| Extra services | Plating / Coating |
| Usage | Pipe Tube Bending |
| Raw Material | Round Pipe Square Tube |
| Keyword | China Pipe Bending Machine |
| Type | Hydraulic Bending Tools |
| Function | Steel Metal Bending |
| Quantity (Sets) | 1 – 1 > 1 |
| Lead Time (Days) | 30 To be negotiated |
Valid from 14/04/2023 to 14/03/2028
Conformité Européene (European Conformity): indicates conformity with health, safety, and environmental protection standards for products sold within the European Economic Area.
| Main Technical Parameter Items | Unit | Value Range |
|---|---|---|
| Maximum applicable carbon steel pipe material (bending radius ≥ 2D) | mm | Φ89×12t |
| Maximum applicable stainless steel pipe (bending radius ≥ 2D) | mm | Φ89×4.0t |
| Maximum core length (*) | mm | 3800 |
| Maximum bending radius (*) | mm | 450 |
| Maximum bend angle | degree | 190 |
| Number of bends per pipe fitting (*) | bends | 25 |
| Number of pipe fitting files can be set expandable | groups | 500 |
| Working speed Bend speed | degree/second | Max.90°/s |
| Machine tool accuracy Bend angle | degree | ±0.1 |
| Oil pressure motor power | Kw | 11 |
| Machine weight | Kg | 3000 |
| Voltage | V /Hz（Can Be customizable） | 380/50（Can Be customizable） |
| Machine size L × W × H (mm) | mm | 5000x1300x1300 |
| Application industry | |||
|---|---|---|---|
| Furniture | Boiler | Exhaust | Shipyard/oil rig |
| Head rest | Heavy vehicle cabin | Green house | Health care |
| Aerospace/aviation | Serpentine bending | Fitness | Brake line |
Pre-service:
1. We will help you confirm the model of our machine according to your offered pipe information.
2. You are very welcome to see how our machine works in the factory before you place an order with us.
Aftersales-service:
1. Our machine is easy to use. The operation manual and teaching video will be sent out with the machine. We also offer free training in our factory, the following is our training contents: Detailed function of our machine, 1 hour; NC control use, 0.5 hours; Tooling installation and adjustment, 0.5-1 hours; Maintenance and repair, 0.5-1 hours; Real operation according to client products, 1-2 hours. During the training period, we offer free pick-up, hotel, and food.
2. We guarantee machine quality for 13 months, during this period, if spare parts of the machine are not man-made damage, we can send the component to the customer by DHL, or TNT freely.
3. Our factory provides the service for the customer forever, if the customer needs operation help, we provide 24-hour on-line reply service.
1: Are you a trading company or manufacturer ?
We are a tube equipment manufacturer with over fifteen years of experience.
2. How to choose the Pipe Bending Machine?
You must provide us with the following detailed information:
-Material Quality
– Bending radius(CLR)
– Max. outside diameter
– Wall thickness range
– The pipe material
– The drawings if possible
3. How long is your delivery time?
The standard model is 10-15 days, the customized model is 30-60 days.
4. Do you provide any training to make sure our users can operate the machine very well?
1)We will provide a detailed video and instruction book for this machine;
2)We also offer training in our factory to all the clients, and we will arrange everything for you during these days in our city, to make sure every client will be the expert in using our machine!
5. How long warranty can you provide?
Our machine warranty is one year, and we use all the stable components with a long working life!
And we can also send our technician to do the after-sale service in the client’s factory!
6. What kind of solution you can offer to make sure your pipe bending machine can do our job?
1)Before you start ordering this valuable machine, you can provide us with your workpiece drawings
2)We will assist you in confirming the model of our machine based on the pipeline information you provided. We can design molds for your product and provide free samples to ensure that your product is qualified before we can confirm the order and provide sample videos.
